Roll Form Tooling

At Roll-Kraft, our legacy has long been established as the industry leader in providing precision roll tooling to tube and pipe producers around the world.

Roll-Kraft combines innovative solutions and high-quality workmanship with its world-class facilities and dedicated staff – resulting in maximum performance, reliability, and value for our customers.

Roll Forming Tooling Design

Quality begins with engineering. Our roll form tooling designers utilize custom-designed software that develops the forming progression and tooling drawings. We have perfected many designs and offer numerous options and roll configurations to best suit your application.

We utilize Finite Element Analysis (FEA) software for specialty or uncommon roll form design applications. This software simulates the tooling design before manufacturing begins. We can better predict specific problems associated with mill configuration, material properties, and reshaping, as never before.

Together with state-of-the-art facilities, quality materials, and a quality management system (ISO 9001:2008 certified), we guarantee your tooling will be designed and built to maximize performance.

Customer Testimonials

testimonial 6atestimonial 7atestimonial 8atestimonial 9atestimonial 10a

See what our customers say, look through our testimonial page and the rest of the web site to see how we continuously improve to make the best products for tube and pipe producers.

Click here to read more testimonials.












Special Roll Tooling Materials:

Soft Urethane – This material is used when grip is needed and the product surface cannot be crushed back flat. Perforated or louvered tubing are examples of uses for this material.

Nylon – Nylon is used when the surface condition of the final product is crucial and no other material will suffice. Dead soft aluminum and some stainless steel tube can be made completely mark free with a nylon application.

AMPCO - AMPCO is used in areas where the absence of marking is critical and more tooling wear is required. It is commonly used in stainless steel applications, as well as for weld rolls, due to its non-magnetic properties. It is available in different grades and levels of hardness.

AMPCO Bronze Weld Rolls

CPM 10V and A11 – These materials can be used in many applications, and they have a longer life than D2 steel. They have worked very well in bead rolling and hammering operations in stainless steel tube and pipe. This material can last two to three times longer than D2 in certain areas when forming carbon steels.

- - - - -

Roll-Kraft Quality

Please keep in mind that anything you order from Roll-Kraft is backed by our 100% performance guarantee.   What does that mean?  It simply guarantees that if you are not satisfied with any of our roll forming products or services, you will receive a replacement or a complete refund.

Use our Quick Contact Form for more information on our roll forming tooling call us toll-free at 888-953-9400.
